The mount consists of three parts: the main under tank plate and two clamp bodies. The under tank plate is CNC Laser Cut from 1/8 inch high strength steel plate. You can weld your own mounting brackets to the bottom if needed or utilize the 8 bolt holes already in the mount. The 2 clamp down bodies capture the top and all four sides of the tank and bolt securely to the mounting base. These parts are CNC Laser Cut but from 18 gauge steel. The parts are formed on a hydraulic press break. This mount will ensure your fuel cell is mounted securely. The Motobilt tank features one fitting on top of the tank which has a roll over valve for a vent line. The MB5005-TJ Fuel Cell already has the provisions for the clamping ring cnc cut into the tank. This means the clamping ring and pump will bolt in with no cutting or drilling necessary!
This fuel cell is used for applications where you are extending the wheel base and the rear axle would contact the factory fuel tank. It would also be used in situations where more ground clearance is needed. This kit works perfectly with the Motobilt Jeep TJ Back Half kit or Motobilt Jeep LJ back half kit, where the frame rails are moved up and in for ultimate clearace.
Features:
- Jeep TJ/LJ aluminum fuel cell
- MB3000 Fuel Cell Mount
- MB50007 TJ fuel pump clamping ring
- 30 inch x 12 inch x 9 inch
- 15 US gallons capacity
- CNC cut from 1/8 inch 5052 aluminum
- Press brake formed
- Includes a large D-ring style cap
- Under tank plate is CNC Laser Cut from 1/8 inch high strength steel plate
- Sold as kit
- Jeep Wrangler TJ | TJ Unlimited 1997-2006
- This Fuel Cell Does Not mount in between the frame rails. It will only mount inside the bed of the Jeep
- We recommend using Permatex 80016 Form-A-Gasket number 2 Sealant to seal the contact surfaces. This is a sealant we have used in the shop numerous times over the years for sealing filler caps on fuel cells.
