The mount consists of three parts the main under tank plate and two clamp bodies. The under tank plate is CNC Laser Cut from 1/8 inch high strength steel plate. You can weld your own mounting brackets to the bottom if needed or utilize the 8 bolt holes already in the mount. The 2 clamp down bodies capture the top and all four sides of the tank and bolt securely to the mounting base. These parts are CNC Laser Cut but from 18 gauge steel. The parts are formed on a hydraulic press break. This mount will ensure your fuel cell is mounted securely.
The Motobilt tank features one fitting on top of the with a 90 degree roll over valve and barbed hose fitting. A 2nd -8 AN fitting has been added for the 2005-2006 models as they require a return line. Older model TJ's will simply cap this fitting off as its not needed on the early models.The MB5010-TJ Fuel Cell already has the provisions for the clamping ring cnc cut into the tank. This means the clamping ring and pump will bolt in with no cutting or drilling necessary! Once the ring is installed, we recommend using Permatex 80016 Form-A-Gasket number 2 Sealant to seal the contact surfaces. This is a sealant we have used in the shop numerous times over the years for sealing filler caps on fuel cells.
This fuel cell is used for applications where you are extending the wheel base and the rear axle would contact the factory fuel tank. It would also be used in situations where more ground clearance is needed. This kit works perfectly with the Motobilt Jeep TJ Back Half kit or Motobilt Jeep LJ back half kit, where the frame rails are moved up and in for ultimate clearance.
Features:
- Fuel tank in your Jeep TJ
- Steel mount
- Fuel pump clamping ring
- 30 inch x12 inch x 12 inch
- Roughly 18.7 US gallons capacity
- CNC cut from 1/8 inch 5052 aluminum
- Press brake formed
- TIG welded for ultimate strength
- Includes a large D-ring style cap
- Under tank plate is CNC Laser Cut from 1/8 inch high strength steel plate
- Sold as kit
- Jeep Wrangler TJ | LJ | TJ Unlimited 1997-2006
- This Fuel Cell Does Not mount in between the frame rails. It will only mount inside the bed of the Jeep
- This Fuel Cell Does Not fit behind the factory seat
- We recommend using Permatex 80016 Form-A-Gasket number 2 Sealant to seal the contact surfaces
⚠ WARNING:
Cancer and Reproductive Harm
https://www.P65Warnings.ca.gov
Motobilt was founded in 2012 by offroading pioneer, Dan DuBose and is located at Ozark, Alabama. The company specializes in creating aftermarket parts for various offroad vehicles and Jeeps. They have consistently provided high-quality products. Hence, they have become the brand of choice by multiple offroaders worldwide.
Proudly made in the USAAll of Motobilt’s products are made in the USA. With more than 40 professionals working in their 85,000 square foot facility, the company is able to maintain and control their high-quality standards and provide their customers with the best value for their money.
Making Use of Advanced TechnologyThe company uses state-of-the-art technology in creating their products such as Laser Cutters, Press brake forming, CNC machines, Tube Benders, MIG and TIG welding machines, and more. They utilize the latest 3D CAD Software to create precise and accurate designs that fit perfectly in the vehicle.
Their products are made out of the best raw materials available in the market. This helps in making their product strong and durable that it can handle the toughest terrain encountered during off-roading.
Purchase Motobilt Products at Vivid RacingIf you want to turn your vehicle into a reliable offroading machine, you need parts designed for the occasion and Motobilt is the brand for you. They offer suspension parts, bumpers, stiffeners, chassis reinforcement parts, billet products, and other offroad accessories. If you want a brand that you can depend on, then you came to the right place. Visit Vivid Racing and check out their list of products that would fit your specific needs.
