SPL Front Swaybar Endlinks Scion | Subaru | Toyota 2013+
$224.10
SPL front adjustable swaybar endlinks for the Toyota GR86/GT86, Subaru BRZ, and Scion FR-S feature massive PTFE-lined FK 1/2" bearings to provide the highest load capacity for use with stiffer aftermarket sway bars. Custom heat-treated chromoly high-misalignment studs allow for extreme articulation angles (up to 65 ) to prevent endlink bind when used with adjustable sway bars.

Unlike OEM, SPL endlinks are adjustable, enabling you to eliminate unwanted preload on the sway bars, set the ideal bar angle, and, if equipped with ride-height adjustable coilovers, properly corner balance your car. The result is better handling, more sway bar tuning options, and less variation in performance between right-hand and left-hand turns. Even stock cars can take advantage of this upgrade by simply dialing out the swaybar preload that occurs when you sit in the car to drive it and from the settling that occurs as the OEM suspension racks up miles.

Easy, On-Car Adjustments: The 6061-T6 turnbuckles use opposing thread patterns (RH and LH) to allow you to adjust the length while it is still installed. Simply turn the turnbuckle to lengthen or shorten the link to the exact desired length and snug the jam nuts.

Noise, Vibration, and Harshness (NVH): The front endlinks are a moderate contributor to NVH. They connect the body (swaybar is mounted to chassis) to the front struts which are hard mounted to the knuckles. This creates a rigid load path for tire vibrations to be transmitted to the chassis, resulting in more tire noise. How much more road noise is transmitted depends on several factors, namely the tires, speed, frequency of the noise, etc. Spherical endlinks can also make the occassional noise over asymmetrical bumps, like driving one wheel at a time over a speed bump or reversing out of a sloped driveway. The front endlinks however, do not increase ride harshness. Suitable for all uses, from daily driver to race car.

Sold as a pair. One pair per vehicle.

Replaces OEM Part Number(s): Toyota-SU003-00394, Subaru-20420-CA000

Installation:
  • Some coilovers and/or setups may require shorter endlinks for proper clearance of the LCA. The OEM length range endlinks (SPL FE FRS) can be adjusted between 9.15" (232mm) and 10.65" (271mm). We offer a shorter endlink setup (SPL FES FRS) that can be adjusted between 7.40" (188mm) and 8.90" (226mm).
  • Installation Guide


Features:
  • Large Adjustability Range
  • Eliminates Swaybar Preload
  • Correct Swaybar Install Angle
  • Lightweight, High Strength Construction
  • Self-Cleaning, US Made, PTFE-Lined FK Bearings


Specifications:
  • 6061-T6 Aluminum Turnbuckle (Anodized Black)
  • FK PTFE-lined 65 Studded Rod Ends (F1 Spec, Self-Cleaning)


Fitment:
  • Toyota GR86 (ZN8) 2021+
  • Toyota 86/Scion FR-S (ZN6) 2013-2021
  • Subaru BRZ (ZC6/ZD8) 2013+
Proposition 65

WARNING: Cancer and Reproductive Harm
https://www.P65Warnings.ca.gov

SPL Suspension Banner

Who is SPL?

SPL is a company known for creating suspension components for the majority of the vehicles of today. They offer various suspension components both for street or racing applications. Their products allow the user to have adjustability in their suspension that helps in improving vehicle handling. Today, they have been chosen by top racing teams and different vehicle enthusiasts who demand performance out of their vehicles.

State-Of-The-Art Facility

The company uses the most advanced manufacturing technology available to aid them in creating a top-quality product. A CNC machine cuts the pieces to tolerances that are within specification. By having their product design in-house, the company can create parts that are better than its competitors. Their product features better designs that allow it to have better adjustability, lower friction, and better fitment. The company pays close attention to detail. Hence, all of their parts are hand-fitted and personally checked for any faults or issues. This assures you that you can only get the best product from them.

Purchase SPL SUspension Product at Vivid Racing

They say a good handling vehicle can elevate the driving experience. If you want to feel this on your own, then why not upgrade your suspension to SPL products. The company offers a complete list of suspension parts from tie rods, caster rods, camber adjustments, lockout kits, and more. They cater to cars from every brand such as Toyota, Subaru, Mitsubishi, Nissan, and infinity, just to name a few. Visit Vivid Racing and check out all the list of products that would fit your specific needs.


ONE-YEAR LIMITED WARRANTY

SPL PRO suspension products warranted to be free of defects in material and workmanship for one (1) year from the date of purchase to the original retail purchaser. Proof of purchase is required for all warranty claims.

If a product fails to meet specifications, SPL PARTS INC will, at its election, repair, replace, or make appropriate adjustment, if SPL PARTS INC determines to its satisfaction that the product is defective in material or workmanship, i.e. contains a defect arising out of the manufacture of the product and not a defect caused by other circumstances, including, but not limited to accident, misuse, abuse, unforeseeable use, neglect, alteration, improper installation, improper adjustment, improper repair, or failure caused by other equipment or interaction with other equipment. SPL PARTS INC is not responsible for labor charges, removal charges, installation, or other incidental or consequential costs. In no event shall the liability of SPL PARTS INC exceed the purchase price of the product. Customers are responsible for shipping costs. All parts for warranty claims must be returned to SPL PARTS INC for inspection and for the claims to be processed.

SPL PARTS INC makes no other warranties, either expressed or implied, including limitation warranties as to merchantability or fitness for a particular purpose. SPL PARTS INC shall not be liable for, and buyer assumes all risk of, any advice or failure to provide advice by SPL PARTS INC to buyer regarding the product or use and installation of product. SPL PARTS INC shall not be liable for any special, incidental or consequential damages.

If the purchaser of the product shall fail to pay when due any portion of the purchase price, or fail to meet any terms required under contract agreed on at time of purchase, all warranties and remedies granted may be terminated.

Using any SPL arm as a tie/strap down point for a dyno session or transport will void the warranty.
