VAG 2. 0 TSI VW Transporter Bus T5 / T6 TTE450 UPGRADE TURBOCHARGER
Welcome to our Ultimate OEM+ Plug & Play Upgrade turbocharger for the 2. 0 TSI T5 / T6 range of vehicles. Ultra-Fast response with big turbo power giving the huge area of power under the curve. A true Stage 3 hybrid.
TTE450 begins life as a brand new original turbocharger that we dismantle and then set about upgrading and optimising as engineers to create our ultimate hybrid. TTE450 Turbocharger is in our opinion is the pinnacle power stage for the T5/T6 range of vehicles while retaining the OE unit for Plug & Play fitment.
Engineered & Enhanced
TThe recipe to making a TTE450 starts with a much larger TTE billet compressor wheel, chosen because is highly efficient, new generation type with very thin blades, creating an extremely high flow for comparative size, giving a compressor map that's very wide. The Re-Profiled compressor cover is machined to an optimised tolerance to ensure maximum compressor efficiency is given.
A key part of driving the large billet TTE compressor and in turn making this unit produce the huge power advantage overstock is machining and fitting a far larger TTE 9 blade High-Flow turbine and shaft, while still keeping the original core, this is not so easy to do. This turbine gives much lower back pressure and keeps EGT lower.
Special TTE developed in-house high-performance motorsport journal bearing system is fitted. Durable at high loads with no loss in transient response.
The actuator used is an uprated sprung OE unit, fitted with our reinforced clamps for trouble-free operation.
Equilibrium
Precisely balancing our turbochargers is a key critical factor to become a TTE upgrade unit as longevity and performance are paramount. Good balance improves acoustics also. Subsequent great care is taken with all TTE turbochargers to achieving our balance standards. Firstly parts are balanced at slow speeds up to 2800RPM in multiple planes using our single parts machine, then components are assembled and then the CHRA are dynamically balanced, but this time depending on the application at up to 250,000 RPM in multiple planes using our in house VSR machine to acquire the ultimate equilibrium, to a standard far higher than OEM. Each turbocharger is supplied with a serial numbered balance test result document.
Features:
- Original Genuine IS38 IHI turbocharger as the base part
- Genuine IHI Housings, Exhaust manifold & Components
- TTE 7x7 Billet Highly Efficient Next Gen Compressor Geometry
- Optimised Compressor Cover Machining Clearances
- CNC Optimised modified silencer discharge delete
- CNC Ported Intake Pipe
- TTE 9 Blade Turbine
- TTE Reinforced Bearing System
- Uprated & Reinforced Actuator
- Fitment As Original. Plug & Play
- 400HP+ Proven using 98ron fuel
- Single parts finely balanced then components assembled and core high-speed VSR balanced
- Supplied with a balance test result document
- Proven TheTurboEngineers Quality
- Made in Germany
- Volkswagen Transporter T5 | T6 2. 0 TSI 2003+
- To utilise your existing turbo, you will need to send us your non-damaged turbo.
- Price shown is based on your turbocharger being undamaged and within specification.
- Remanufacturer Turbos must have core sent to TTE
- Turbochargers must be in good working order and free from damage, any turbochargers sent with damage may incur extra charges.
⚠ WARNING:
Cancer and Reproductive Harm
https://www.P65Warnings.ca.gov
Who Is TTE Turbo?
The Turbo Engineers GmbH (also called TTE Turbo) is a dynamic and highly innovative turbocharger engineering company headquartered in Dachau, just on the outskirts of Munich in Germany. The brand specializes in the production of motorsport upgrade turbochargers to the highest level of quality and greatest efficiency. With strict attention to detail and rigorous testing methods, TTE Turbo offers a comprehensive line of top-notch turbocharger upgrades that deliver proven results. You can count on TTE Turbo to deliver a long-time, reliable, and optimized system for your car to achieve the maximum power and performance possible.
What Does TTE Turbo Offer?TTE Turbo is focused on the construction of prototypes through the concept stage all through completion with most of the work being done in-house to its own stringent standards. The team places a large focus on converting existing OE turbochargers to newly upgraded specs for enhanced results. During the design and testing process, TTE turbochargers are thoroughly tested and refined to create a final product that emphasizes both performance and long-term reliability.
TTE Turbo is highly regarded in the automotive community as it consults and provides its parts to race teams and well-known tuners all around the globe. The company covers a wide array of automakers, including Alfa Romeo, AMG, Aston Martin, BMW, Ferrari, Ford, Lamborgini, McLaren, Nissan, Porsche, Renault, Toyota, and Volkswagen.
Upgrade to a TTE Turbo at Vivid RacingIf you are looking for the best-engineered performance turbochargers on the market, TTE Turbo is the way to go. Vivid Racing carries an impressive lineup of parts from The Turbo Engineers, including heat shields and wraps, intake adapters, silencer deletes, performance turbocharger systems, and remanufactured turbos. Should you have any questions about TTE Turbo, please contact us at (480) 966-3040.
