VTT Modular PCV/Catch Can (Dual Can External PCV) - VTT-OCC-2-DUAL-CAN-EXTERNAL-PCV
VTT Modular PCV/Catch Can (Dual Can External PCV) - VTT-OCC-2-DUAL-CAN-EXTERNAL-PCV - Image 4 VTT Modular PCV/Catch Can (Dual Can External PCV) - VTT-OCC-2-DUAL-CAN-EXTERNAL-PCV - Image 2 VTT Modular PCV/Catch Can (Dual Can External PCV) - VTT-OCC-2-DUAL-CAN-EXTERNAL-PCV - Image 3 VTT Modular PCV/Catch Can (Dual Can External PCV) - VTT-OCC-2-DUAL-CAN-EXTERNAL-PCV - Image 4
VTT is proud to announce a ground-up system designed to give the end-user complete control over their valve cover/ PCV setup. Tired of being told you will run two -10 lines from your VC to your Catch Can? So were we. Now you can run them any way you want, including complete VTA, oil cap one-way breather, etc. Nothing on the market comes close to the versatility of this setup, and it truly is the ULTIMATE Valve cover, PCV combo, or Valve cover, or PCV setup. You choose how many or how few you want to run. Check out this video highlighting some of the features then rea.

This option allows you to purchase a ready-to-install kit with all fittings, hoses, check valves, etc. for you to bolt on, and go. Prices vary by kit.

Kit Break down is as follows:

Single Can Stock Valve Cover Stock PCV
  • One Catch Can
  • One N54 bracket
  • One or Two -10 Low Profile  Steel 90 fitting depending on options or banjos
  • High side -10 adapter fitting
  • Hose from High Side to Can
  • Hose from can to Rear inlet (Or Breather)
Single Can Stock Valve Cover External PCV (High side remains stock)
  • One Catch Can
  • One N54 bracket
  • Two -10 Low Profile  Steel 90 fitting or banjos
  • Low Side -8 adapter fitting
  • Vacuum Adapter fitting for Throttle body
  • Inline Check Valve
  • Hose from Adapter fitting to Can
  • Hose from Low Side to Can
  • Head Port Block off kit (optional)
Dual Can Stock Valve Cover (External PCV only)
  • Two Catch Cans
  • One N54 bracket
  • Four -10 Low Profile  Steel 90 fitting (or three if the breather is ordered) Or Banjos
  • High side -10 adapter fitting
  • Low Side -8 adapter fitting
  • Hose from High Side to Can
  • Hose from High side can to Rear inlet (or breather)
  • Vacuum Adapter fitting for Throttle body
  • Inline Check Valve
  • Hose from Adapter fitting to Can
  • Hose from Low Side to Can
  • Head Port Block-off kit (optional)
Single Can VTT Modular Valve cover (External PCV only)
  • One Catch Can
  • One N54 bracket
  • Two -10 Low Profile  Steel 90 fitting Or banjos
  • Two -10 ORB Plugs
  • Hose from Valve Cover to Can
  • Hose from Can to Vacuum adapter fitting
  • Inline Check Valve
  • Head Port Block-off kit (optional)
Dual Can VTT Modular Valve Cover (External PCV only)
  • Two Catch Cans
  • One N54 bracket
  • Four -10 Low Profile Steel 90 fitting (or three if the breather is ordered for the high side) Or Banjos
  • Vacuum Adapter fitting for Throttle body
  • Two Hoses from Valve Cover to Cans
  • Hose from Low side can to Vacuum Adapter fitting
  • Hose from High Side can to Rear inlet (or breather)
  • Inline Check Valve
  • Head port block-off kit (optional)
Catch Can Details:
  • 100% CNC 6061-T6 Aircraft aluminum construction
  • Gives the end user true variety for setting up their Valve Cover and PCV System
  • Lower pricing than other non-modular options on the market
  • Site glass for easy viewing when draining is required
  • Optional -6 ORB drain cock with fittings for 1/8NPT barb
  • Single or dual can fit on the same bracket
  • Can be used with Vacuum or VTA
Note:
  • These catch cans do not fit with the standard cowl in place without modifying the cowl. These are for vehicles that run with the cowl removed, and cowl filters such as BMS.
  • The stainless breather will not fit on the left can when using the fab factory manifold.  If you plan on removing the stock PCV valve to run our external kit our PCV delete fitting will block the passage from the head ports. We suggest you block your head ports if you plan to run 25+PSI of boost, kit is available in the drop-downs
